Engineering Products for Oil & Gas | Petrochemical | Power | Desalination

Quality can be measured. Flow elements and special piping products made for demanding process systems.

Gulf Oil & Gas International (GOI Intl) - FZE designs, provides, and supplies high-precision differential pressure flow elements, specialized piping products, and custom-fabricated process piping assemblies for critical energy, refining, chemical, paper, food, and utility infrastructure worldwide.

Design ISO 5167 / ASME Sizing & Calculations
Provide Full Material Stock & Same-Day Dispatch
Supply Global EPC Project & Turnaround Export

Complete Product Scope

Precision-machined primary flow elements, fluid conditioning devices, line restriction assemblies, filtration units, process sampling instruments, and certified piping spools.

Flow Measurement Products & Primary Elements

Engineered differential pressure flow metering equipment designed and calculated in accordance with ISO 5167, AGA Report No. 3, ASME MFC-3M, DIN, and JIS standards.

Orifice Plates & Restriction Spools

GOI International provides standard orifice plates in stainless steel 316L with Raised Face (RF) gasket surfaces and EN 10204 3.1B material certificates. All custom materials, RTJ oval/octagonal configurations, and DIN/JIS standards are readily supplied. GOI International stamps the measured orifice diameter directly onto the tagplate for exact flow computer integration, backed by comprehensive strength calculations against line pressure loss. Single-bore restriction plates and multi-stage restricted orifice (RO) spools are engineered for anti-cavitation and severe noise suppression.

Orifice Flanges & Meterruns

Orifice flanges are provided as standard according to ASME B16.36 with 1/2" NPT flange tappings, plugs, and jackscrews. Complete assemblies include orifice plates, studbolts, nuts, and gaskets, with optional SW, BW, plain-end, or flanged welding nipples. Meterruns are fabricated per ISO 5167, ASME B31.3, and international pressure vessel rules, available with corner, radius, or pipe tappings and dowel pins to ensure exact axial alignment.

Flow Nozzles & Venturi Nozzles

Long Radius and ISA 1932 Flow Nozzles are precision-machined from forged solid bar stock for weld-in installation or clamping between flanges with matched spacer rings and gaskets. Venturi Nozzles (ISO 5167 / DIN 1952) are machined from solid forged bars up to 12" (DN300) for maximum roundness, and forged/rolled combinations for larger sizes with all inner seam welds machined flush with the internal pipe bore.

Classical Venturi Tubes (Types A, B, C)

GOI International provides all three classical Venturi Tube types under ISO 5167: Type A (cast convergent section), Type B (precision-machined convergent section across inlet/outlet ranges), and Type C (machined/honed throat section with rough-welded sheet steel inlet/outlet cones, external structural stiffeners, and integral lifting lugs).

Flow Straighteners & Conditioners

Designed to eliminate fluid swirl, cross-flow velocities, and severe velocity profile distortion where installing sufficient straight upstream pipe length is physically impossible. GOI International provides Zanker, Etoile star-vane, Sprenkle multi-plate, 19-Tube Bundle, AMCA, and AGA/ASME perforated straighteners in any required dimension and metallurgical grade.

Senior & Junior Orifice Fittings

Single-chamber Junior fittings and dual-chamber Senior orifice fittings allowing fast, safe orifice plate inspection and replacement under full line operating pressure without process shutdown, venting, or expensive bypass line loops.

Special Piping Products & Instrumentation Hardware

Engineered piping accessories, mechanical protection devices, and fluid sampling solutions designed to client datasheets and international piping codes.

Sample Coolers & Cabinets

GOI International provides sample coolers and automated sampling cabinets designed to cool high-temperature process fluids and boiler blowdown. Coils are supplied in any required metallurgy with Socket Weld (SW) connections as standard, or optional flanged/threaded ends, complete with support legs or mounting brackets.

Strainers & Bird Screens

Covered under our ISO 9001 quality system, GOI International provides T-type, Y-type, bucket-type (basket), and conical temporary start-up strainers manufactured from pipe, fittings, plate, or castings. Each unit is checked for strength and open area ratio to provide optimal equipment protection with minimal pressure loss, supported by WPS/PQR and NDE dossiers. Intake bird screens are supplied in heavy-gauge mesh.

Thermowells

GOI International provides thermowells machined from solid forged barstock in any length or standard drawing profile (threaded, socket-weld, or flanged). Flanged joints are welded by qualified welders backed by complete Welder Qualification Records (WPQR). Extensive stocks of carbon and stainless steels ensure rapid delivery.

Spectacle Blinds, Spades & Spacers

Precision flame-cut from heavy plate material and machined with smooth or stock finish gasket contact surfaces (as well as RTJ male/female grooves). Welded by qualified personnel per ASME B16.48. Sizes over 8" are supplied with integral lifting lugs, complete with client-specified color coding.

Sample & Injection Quills (Retrievable-Type)

Specialized quills designed to safely introduce treatment chemicals or extract fluid samples from pressurized lines. GOI International rigorously evaluates wake frequency, vortex shedding, and unsupported insertion length to ensure mechanical integrity, chemical compatibility, and vibration safety.

Level Chambers, Gaskets & Ejectors

External bypass level chambers (bridles/cages) allow live maintenance and calibration of level transmitters without process shutdown. We also provide Flange Insulation Sets (Type F, E, and D) with dielectric sleeves/washers, Spiral Wound Gaskets rated up to 250 bar (-200°C to +450°C), steam ejectors, and process desuperheaters.

Technical Specifications & Ordering Matrix

Engineered execution standards, metallurgical grades, sizing capabilities, and quality control parameters across our complete product scope.

Engineering Parameter Design Standards, Metallurgical Grades & Sizing Capabilities
Design & Construction Codes ISO 5167 (Parts 1–4), ISO 5167-3, AGA Report No. 3 (API 14.3), ASME MFC-3M, ASME B31.3, ASME B31.1, ASME B16.36, ASME B16.5, ASME B16.48, DIN 1952, JIS, BS 1042, Stoomwezen Rules
Nominal Line Sizes 1/2" NB to 60" NB (DN15 to DN1500) and custom fabricated large-diameter spools
Pressure Classes & Ratings ASME Class 150# through 2500# | DIN/EN PN10 through PN420 | API 2000 to 15000 PSI | Spiral wound gaskets up to 250 bar
Temperature Ratings Cryogenic (-200°C) to elevated high-temperature steam services (>450°C to 650°C)
Carbon & Low-Temp Steels ASTM A105N, ASTM A350 LF2, ASTM A106 Gr. B, ASTM A333 Gr. 6, ASTM A516 Gr. 60/70, ASTM A234 WPB/WPL6, C21
Chrome-Moly Alloy Steels ASTM A182 / A335 / A234 Gr. F5, F9, F11, F22, F91, P11, P22, P91 (High-pressure boiler steam service)
Stainless Steels ASTM A182 / A312 / A240 Gr. 304, 304L, 316, 316L (Standard stock), 316Ti, 321, 347, 310, 904L
Duplex & Super Duplex UNS S31803 / S32205 (2205 Duplex, 1.4462), UNS S32750 / S32760 (2507 Super Duplex, Zeron 100)
Nickel Alloys & Exotics Inconel 625, Inconel 825, Hastelloy C276, Hastelloy C22, Monel 400, Alloy 20, Titanium Gr. 2 / Gr. 5, Tantalum, PTFE-coated
Quality Assurance & Testing ISO 9001 Quality System, EN 10204 3.1B / 3.2 Material Certificates, NACE MR0175/ISO 15156 Sour Service, WPS/PQR Qualified Welds, Radiography (RT), Ultrasonic (UT), Magnetic Particle (MPI), Dye Penetrant (DPT), Positive Material Identification (PMI), Hydrostatic Testing, ISO 5167 Flow Computer Sizing

Design Verification, Strength Calculations & Rapid Dispatch

GOI International stamps the measured orifice diameter directly onto the tagplate for precise flow computer configuration and provides finite strength calculations verifying plate thickness against maximum pressure differential ($\Delta P$). With extensive base material stocks across standard carbon and stainless steels, GOI International accommodates urgent shutdown turnarounds and fast-track projects with same-day emergency dispatch options.

Industries We Serve

Reliable engineered products for applications where accurate flow measurement, process integrity, and dependable fabrication are essential.

Oil & Gas (Upstream & Offshore)

Wellhead flow metering, high-pressure separator runs, gas lift restriction spools, fiscal custody transfer meter runs, retrievable corrosion injection quills, and topside FPSO modular spools.

Refineries & Petrochemicals

Severe service hydrocarbon flow nozzles, multi-stage RO spools, steam ejectors, process desuperheaters, duplex basket strainers, sample coolers, and ASME spectacle blinds.

Power Generation & Steam Systems

ASME PTC 19.5 flow nozzles, ISA 1932 nozzles for superheated steam, boiler feed water venturi tubes, condensate sample coolers, high-pressure thermowells, and level chambers.

Water & Desalination (SWRO)

High-volume intake venturi tubes, Super Duplex (2507) restriction orifices, brine discharge strainers, suction diffusers, chemical dosing quills, and epoxy-coated transmission piping.

Chemical, Paper & Fertilizer

Hastelloy and Monel flow elements, corrosive acid injection quills, specialized jacketed piping spools, and custom-alloy thermowells engineered for aggressive media.

Food, Pharma & General Industry

Sanitary stainless steel piping components, utility steam flow conditioners, boiler water sampling cabinets, and industrial process skid packages.

Process Piping Fabrication & Skid Manufacturing

We specialize in precision fabrication work for process piping and engineered assemblies, from individual calibrated spools to complete skid packages.

Process Piping Spools

Custom-fabricated piping spools manufactured according to approved isometric drawings, piping classes, material specifications, and ASME B31.3 / B31.1 quality standards.

Skids & Packaged Assemblies

Fabrication of modular metering skids, multi-valve manifold headers, chemical injection skids, and structural skid packages ready for site hook-up.

WPS & PQR Documentation

Comprehensive welding procedure specifications (WPS) and procedure qualification records (PQR) qualified to ASME Section IX and EN ISO standards for all alloy classes.

Technical Manufacturing Dossiers

Complete project QA/QC dossiers including approved GA drawings, 3.1 material test certificates, NDT inspection reports, hydrostatic test charts, and painting/coating inspection records.

Custom Engineering & Sizing

In-house thermal, hydraulic, and differential pressure sizing based on client process datasheets, line lists, fluid physical properties, and operating scenarios.

Project & Turnaround Supply

Dedicated fast-track manufacturing capabilities supporting major EPC capital projects, plant debottlenecking, emergency shutdown turnarounds, and routine MRO replacements.

Frequently Asked Questions (FAQ)

Technical guidance on selecting, engineering, and procuring differential pressure flow elements and special piping products.

What differential pressure flow elements does GOI International provide?

GOI International provides complete differential pressure flow measurement equipment including standard SS316L and custom alloy orifice plates with stamped bore tagplates, ASME B16.36 orifice flanges, ISO 5167 meter runs with dowel alignment pins, forged Long Radius & ISA 1932 flow nozzles, DIN 1952 venturi nozzles, classical venturi tubes (Types A, B, and C), Junior and Senior orifice fittings, and flow straighteners/conditioners.

What are the three classical Venturi Tube types provided under ISO 5167?

Under ISO 5167, GOI International supplies: Type A with cast convergent inlet; Type B with full CNC machined convergent section across the ISO 5167 range; and Type C fabricated from machined/honed throat sections with sheet steel welded inlet/outlet cones, structural stiffeners, and integral lifting lugs.

How does GOI International ensure safety for sample and injection quills?

GOI International designs fixed, retractable, and retrievable sample and injection quills taking into account wake frequency calculations, fluid chemical compatibility, unsupported insertion length, and mechanical resonance to ensure safe pressurized pipeline injection and fluid extraction.

What configurations of Flange Insulation Sets and Gaskets are supplied?

We supply Type F (inside bolt circle), Type E (full face), and Type D (RTJ) flange insulation sets complete with dielectric sleeves and washers to eliminate electrolytic corrosion, as well as semi-metallic Spiral Wound Gaskets rated up to 250 bar and temperature ranges from -200°C to over +450°C.

Why are external mounting Level Chambers (Bypass Bridles) utilized?

External Level Chambers isolate process instrumentation from the main storage vessel or reactor, allowing live instrument maintenance, testing, and servicing without depressurizing or shutting down the operating system.

What QA/QC documentation and rush delivery options are available?

All equipment is covered by our ISO 9001 Quality System with EN 10204 3.1B/3.2 certificates, WPS/PQR qualified welding, NDE reports, and strength calculations. Stocked base materials enable rapid dispatch, with same-day emergency delivery available for standard sizes.

Global Supply Hubs & Regional Service Coverage

Gulf Oil & Gas International (GOI Intl) supplies standard and custom-engineered flow elements, special piping products, and fabricated spools directly to project sites, refineries, and EPC contractors across the following territories:

Middle East & GCC

  • United Arab Emirates (UAE): Dubai, Abu Dhabi, Sharjah, Ajman, Ras Al Khaimah, Fujairah, Al Ain
  • Saudi Arabia (KSA): Riyadh, Jeddah, Dammam, Al Khobar, Dhahran, Jubail Industrial City, Yanbu
  • Qatar: Doha, Ras Laffan, Mesaieed, Dukhan
  • Oman: Muscat, Sohar, Salalah, Duqm
  • Kuwait & Bahrain: Kuwait City, Ahmadi, Manama
  • Iraq & Levant: Baghdad, Basra, Erbil, Sulaymaniyah, Amman, Beirut, Sanaa, Aden

Africa (North & Sub-Saharan)

  • North Africa: Cairo, Alexandria (Egypt); Algiers, Hassi Messaoud (Algeria); Tripoli, Benghazi, Misrata (Libya); Rabat, Casablanca (Morocco); Tunis (Tunisia); Nouakchott (Mauritania); Khartoum (Sudan)
  • West & Central Africa: Lagos, Abuja, Port Harcourt (Nigeria); Accra, Takoradi, Tema (Ghana); Abidjan (Ivory Coast); Dakar (Senegal); Luanda, Soyo, Cabinda (Angola); Libreville (Gabon); Pointe-Noire (Congo); Malabo (Equatorial Guinea); N'Djamena (Chad)
  • East & Southern Africa: Nairobi, Mombasa (Kenya); Dar es Salaam (Tanzania); Kampala (Uganda); Maputo (Mozambique); Lusaka (Zambia); Windhoek (Namibia); Johannesburg, Cape Town, Durban (South Africa)

CIS & Central Asia

  • Kazakhstan: Almaty, Astana, Aktau, Atyrau, Shymkent
  • Azerbaijan: Baku, Sumqayit
  • Turkmenistan: Ashgabat, Turkmenbashi
  • Uzbekistan: Tashkent, Bukhara, Navoi, Fergana
  • Caucasus & Central Asia: Tbilisi (Georgia), Yerevan (Armenia), Bishkek (Kyrgyzstan), Dushanbe (Tajikistan)

Talk to us about your requirement.

Send your process datasheets, isometric drawings, line classes, material grades, operating pressure/temperature, inspection scope, and delivery location.

Design · Provide · Supply

Our engineering team will review your project parameters and respond with a comprehensive technical proposal.
